    Stainless Steel Weight Level Shear Beam Digital Load Cell 500kg

    Ask Lasest Price
    Brand Name : Fibos
    Model Number : FA509
    Certification : CE,ROHS,ISO9001
    Price : USD 68-138/PC
    Payment Terms : Western Union, MoneyGram, T/T, L/C
    Supply Ability : 1000per month
    Delivery Time : 7-14work days
    • Product Details
    • Company Profile

    Stainless Steel Weight Level Shear Beam Digital Load Cell 500kg

    Weight

    Weight

    Product Description

    Parameters

    Values
    Capacity

    0.22/0.55/1.1/1.76/2.2/4.4t

    Rated output1.94±1%mV/V
    Zero Balance±2%mV/V
    Creep(30min)≤0.0166%F.S.
    Non-linearity≤0.017%F.S.
    Hysteresis≤0.017%F.S.
    Repeatability≤0.017%F.S.

    Input Resistance

    390±3Ω
    Output Resistance350±5Ω
    Temp.effect on output
    0.014%F.S./10 °C
    Temp.effect on zero
    0.012%F.S./10 °C
    Insulation resistance≥5000MΩ/100V(DC)
    Recommended excitation5~12V
    Maximum excitation15V
    Compensated Temp Range-10~60 °C
    Operating Temp Range-20~80 °C

    Safe Load Limit

    150%F.S.

    Breaking Load

    200%F.S.
    Cable size
    ∅5.4x1.5m
    Material
    Stainless steel

    WeightWeightWeight


    WeightWeight

    Product Description

    WeightWeightWeightWeight


    Weight

    Company Information

    Weight


    The core team of Fibos has 20 years of experience in the design and production of advanced sensors in Germany. We continuously develop and produce: precision micro and small force sensors, dynamic and static torque sensors, six-dimensional force, three-dimensional force, multi-dimensional force sensors, load cells, custom ring force sensors, thread force sensors, thread preload force sensors, sensors for robots, tension series and various non-standard force sensors, etc. The company produces pressure force sensors: accurate measurement, low height, small deformation, high precision, good stability, fast response, easy installation, long life, complete specifications and sizes, not only for push and pull meters, hopper scales, a variety of industrial weighing systems, automotive press assembly, automated assembly, 3C product testing; also used in new energy product assembly, medical testing, textiles, robotics, mold assembly, wind energy, nuclear power and ships, etc. The product dynamic response frequency is high, also can accept custom specifications. In the application of high-frequency loud, fatigue strength after the test, life use up to 100 million times, suitable for all kinds of aircraft, automotive testing occasions.Weight
