Stainless steel/Aluminium alloy Static torque sensors 1~150N.m
Torque Transducer
1. Descriptions
1-150N·M Aluminum Alloy Discontinuous Static Torque Sensor Force
Torque Sensor FA601 is a model of our brand FIBOS FA6-Series,
Static Torque Sensor Force Torque Sensor FA601 can be used to
measure Static Torque force 1N.m,2N.m,3N.m,5N.m,6N.m,10N.m,20N.m,30N.m,50N.m,100N.m and 150N.m capacity, its Rated output range is 2.0±1%mV/V, and its
Zero Balance range is ±1%F.S..
2. Specifications
| Product name | static torque sensor |
| Capacity | 1,2,3,5,6,10,20,30,50,100,150N.m |
| Rated output | 1.5±10%mV/V |
| Zero Balance | ±0.02mV/V |
| Creep(30min) | ≤0.1%F.S. |
| Non-linearity | ≤0.1%F.S. |
| Hysteresis | ≤0.1%F.S. |
| Repeatability | ≤0.05%F.S. |
| Input impedance | 350±5Ω |
| Output impedance | 350±5Ω |
| Temp.effect on output | 0.05%F.S./10 ℃ |
| Temp.effect on zero | 0.05%F.S./10 C |
| Insulation resistance | ≥5000MΩ/100V(DC) |
| Recommended excitation | 5~15V |
| Maximum excitation | 20V |
| Compensated Temp Range | -10~60 ℃ |
| Operating Temp Range | -20~80 ℃ |
| Safe overload | 150%F.S. |
| Ultimate overload | 200%F.S. |
| Cable size | ⌀3x3000mm |
3. Dimension
Advantages of Static Torque Transducers.
1. Extremely robust
2. Best quality
3. No wear and tear
4. Proven technology
5. Customisable scaling of the required measuring range
6. Highly accurate signals (no signal falsification)
7. fast signal output for applications up to 30,000 rpm
8. Miniature versions and multicomponent sensors also available
4. Application
1-150N·M Aluminum Alloy Discontinuous Static Torque Sensor Force
Torque Sensor FA601 could be used in test systems for static torque detection.
1. Marine/Offshore
2. Automotive industry
3.Aerospace
4.Vitality
5.Research and development
6.Laboratory
7.Testing equipment
