5-100kN Stainless Steel Tension Compression Force Sensor
1. Descriptions
5-100kN Stainless Steel Tension Compression Force Sensor FA411 is a
model of our brand FIBOS FA4-Series, Tension Compression Force
Sensor FA411 can be used to measure tension and compression force
5kN,10kN,20kN,50kN and 100kN capacity, its Rated output range is 1.0±10%mV/V, its
Creep(30min),Non-linearity and Hysteresis all ≤0.2%F.S., its
Repeatability ≤0.1%F.S..
2. Specifications
| Product name | Tension Compression Force Sensor |
| Capacity | 5,10,20,50,100kN |
| Rated output | 1.0±10%mV/V |
| Zero Balance | ±0.05mV/V |
| Creep(30min) | ≤0.2%F.S. |
| Non-linearity | ≤0.2%F.S. |
| Hysteresis | ≤0.2%F.S. |
| Repeatability | ≤0.1%F.S. |
| Input impedance | 780±10Ω |
| Output impedance | 700±5Ω |
| Temp.effect on output | 0.05%F.S./10 ℃ |
| Temp.effect on zero | 0.05%F.S./10 ℃ |
| Insulation resistance | ≥5000MΩ/100V(DC) |
| Recommended excitation | 5~15V |
| Maximum excitation | 20V |
| Compensated Temp Range | -10~60 ℃ |
| Operating Temp Range | -20~80 ℃ |
| Safe overload | 150%F.S. |
| Ultimate overload | 200%F.S. |
| Cable size | ⌀5x3000mm |
| Weight | - |
| Material | Stainless steel |
3. Dimension
4. Application
5-100kN Stainless Steel Tension Compression Force Sensor FA411 can
be used in industrial weighing systems.
5.FAQ
Q1: What is your terms of delivery?
A: EXW, FOB, CFR and CIF.
Q2: Can you produce according to the samples?
A: Yes, we can produce according to your samples or technical
drawings.
Q3:What is your sample policy?
A: We can supply the sample with discount if we have ready parts in
stock, and customers pay the courier cost.
Q4: What's your quality guarantee policy?
A: Quality guarantee: 12 months.
If the product has quality problem within 12 months, please return
it to us, we will repair it, if we can't repair it successfully, we
will give you a new one; but the man-made damage, improper
operation and force majeure will be excepted.
And you will pay the shipping cost of returning to us, we will pay
the shipping cost of delivering to you.
