300kg IP68 Alloy Steel Single Point Weight Sensor
1. Descriptions
300kg IP68 Alloy Steel Single Point Weight Sensor FA910 is a model
of our brand FIBOS FA9-Series, Single Point Weight Sensor FA910 can
be used to measure weight 300kg capacity, its Rated output range is
2.0±0.2%mV/V, its Zero Balance range ≤1%F.S., its
Creep(30min),Non-linearity and Hysteresis all ≤0.3%F.S. and its
Repeatability ≤0.1%F.S..
2. Specifications
| Product name | Single Point Weight Sensor |
| Capacity | 300kg |
| Rated output | 2.0±0.2%mV/V |
| Zero Balance | ≤1%F.S. |
| Creep(30min) | ≤0.3%F.S. |
| Non-linearity | ≤0.3%F.S. |
| Hysteresis | ≤0.3%F.S. |
| Repeatability | ≤0.1%F.S. |
| Input impedance | 750±30Ω |
| Output impedance | 700±10Ω |
| Temp.effect on output | ≤ 0.05%F.S./10 ℃ |
| Temp.effect on zero | ≤ 0.05%F.S./10 ℃ |
| Insulation resistance | ≥5000MΩ/50V(DC) |
| Recommended excitation | 5~12V |
| Maximum excitation | 15V |
| Compensated Temp Range | -10~40 ℃ |
| Operating Temp Range | -20~60 ℃ |
| Safe overload | 150%F.S. |
| Ultimate overload | 200%F.S. |
| Material | Alloy steel |
| IP Class | IP68 |
3. Dimension
4. Application
300kg IP68 Alloy Steel Single Point Weight Sensor FA910 could be used for conveyor weighing.
