0.1-20kN Stainless Steel Column Type Load Cell
1. Descriptions
0.1-20kN Stainless Steel Column Type Load Cell FA406 is a model of
Column Type Load Cell, it belongs to our brand FIBOS FA4-Series,
FA406 could be used to measure load 0.1kN, 0.2kN, 0.5kN, 1kN, 2kN, 5kN, 10kN and 20kN capacity, its
Creep(30min), Non-linearity and Hysteresis all ≤0.1%F.S., its
Repeatability ≤0.05%F.S., its weight is 0.3kg.
2. Specifications
| Product name | Column Type Load Cell |
| Capacity | 0.1,0.2,0.5,1,2,5,10,20kN |
| Rated output | 2.0±10%mV/V |
| Zero Balance | ±0.05mV/V |
| Creep(30min) | ≤0.1%F.S. |
| Non-linearity | ≤0.1%F.S. |
| Hysteresis | ≤0.1%F.S. |
| Repeatability | ≤0.05%F.S. |
| Input impedance | 385±10Ω |
| Output impedance | 350±5Ω |
| Temp.effect on output | 0.05%F.S./10 ℃ |
| Temp.effect on zero | 0.05%F.S./10 ℃ |
| Insulation resistance | ≥5000MΩ/100V(DC) |
| Recommended excitation | 5~15V |
| Maximum excitation | 20V |
| Compensated Temp Range | -10~60 ℃ |
| Operating Temp Range | -20~80 ℃ |
| Safe overload | 150%F.S. |
| Ultimate overload | 200%F.S. |
| Cable size | ⌀3x3000mm |
| Weight | 0.3kg |
| Material | Stainless steel |
3. Dimension
4. Application
0.1-20kN Stainless Steel Column Type Load Cell could be applied in
silos measuring.
