Fibos FA402 High Precision 50kg Mini Force Sensor For Machine
Manufacturing
1. Descriptions
50kg The Creep ≤0.05%F.S. Stainless Steel Spoke Type Load Cell
FA401 belongs to FA411 which is in Spoke Type Load Cell category of
our brand FIBOS FA1-Series, Spoke Type Load Cell FA401 can be used
to measure load 50kg capacity, its Creep(30min) ≤0.05%F.S., its
Non-linearity and Repeatability both ≤0.05%F.S., and its Hysteresis
≤0.05%F.S..
2. Specifications
| Product name | 50kg mini force sensor |
| Capacity | 1, 2, 3, 5, 10, 20, 30, 50kg |
| Sensitivity | 2.0±10%mVN |
| Zero Balance | ±0.05%F.S |
| Creep(30min) | ≤0.05%F.S. |
| Non-linearity | ≤0.05%F.S. |
| Hysteresis | ≤0.05%F.S. |
| Repeatability | ≤0.05%F.S. |
| Input impedance | 350±5Ω |
| Output impedance | 350±5Ω |
| Temp.effect on output | 0.025%F.S./10 ℃ |
| Temp.effect on zero | 0.025%F.S./10 ℃ |
| Insulation resistance | ≥5000MΩ/100V(DC) |
| Recommended excitation | 5V |
| Maximum excitation | 15V |
| Compensated Temp Range | -10~60 ℃ |
| Operating Temp Range | -20~80 ℃ |
| Safe overload | 150%F.S. |
| Ultimate overload | 200%F.S. |
| Cable size | ⌀2x3m |
| Material | Stainless steel |
3. Dimension
4. Application
50kg The Creep ≤0.05%F.S. Stainless Steel Tensile-compressive force sensor FA402 can be used for machine manufacturing.
5.FAQ
Q1: What is your terms of delivery?
A: EXW, FOB, CFR and CIF.
Q2: Can you produce according to the samples?
A: Yes, we can produce according to your samples or technical
drawings.
Q3:What is your sample policy?
A: We can supply the sample with discount if we have ready parts in
stock, and customers pay the courier cost.
Q4: What's your quality guarantee policy?
A: Quality guarantee: 12 months.
If the product has quality problem within 12 months, please return
it to us, we will repair it, if we can't repair it successfully, we
will give you a new one; but the man-made damage, improper
operation and force majeure will be excepted.
And you will pay the shipping cost of returning to us, we will pay
the shipping cost of delivering to you.
